CFM-80Cシリーズ
80 mm x 80 mm DC軸状ファン、 omniCOOL™ベアリング
| 製品番号 | 説明 | データシート | 在庫確認 | |
|---|---|---|---|---|
|
CFM-8025C-125-290 | 12V, 120mA, 80 x 80 x 25mm, Dc Fan | ||
|
CFM-8025C-130-330 | 12V, 210mA, 80 x 80 x 25mm, Dc Fan | ||
|
CFM-8025C-135-364 | 12V, 330mA, 80 x 80 x 25mm, Dc Fan | ||
|
CFM-8025C-225-290-22 | 24V, 80mA, 80 x 80 x 25mm, Dc Fan, タコメータ信号, PWM制御信号 | ||
|
CFM-8025C-230-330-22 | 24V, 110mA, 80 x 80 x 25mm, Dc Fan, タコメータ信号, PWM制御信号 | ||
|
CFM-8025C-235-364-22 | 24V, 150mA, 80 x 80 x 25mm, Dc Fan, タコメータ信号, PWM制御信号 | ||
|
CFM-8025C-125-290-22 | 12V, 120mA, 80 x 80 x 25mm, Dc Fan, タコメータ信号, PWM制御信号 | ||
|
CFM-8025C-130-330-22 | 12V, 210mA, 80 x 80 x 25mm, Dc Fan, タコメータ信号, PWM制御信号 | ||
|
CFM-8025C-135-364-22 | 12V, 330mA, 80 x 80 x 25mm, Dc Fan, タコメータ信号, PWM制御信号 | ||
|
CFM-8025C-225-290-20 | 24V, 80mA, 80 x 80 x 25mm, Dc Fan, タコメータ信号 | ||
|
CFM-8025C-230-330-20 | 24V, 110mA, 80 x 80 x 25mm, Dc Fan, タコメータ信号 | ||
|
CFM-8025C-235-364-20 | 24V, 150mA, 80 x 80 x 25mm, Dc Fan, タコメータ信号 | ||
|
CFM-8025C-125-290-20 | 12V, 120mA, 80 x 80 x 25mm, Dc Fan, タコメータ信号 | ||
|
CFM-8025C-130-330-20 | 12V, 210mA, 80 x 80 x 25mm, Dc Fan, タコメータ信号 | ||
|
CFM-8025C-135-364-20 | 12V, 330mA, 80 x 80 x 25mm, Dc Fan, タコメータ信号 | ||
|
CFM-8025C-225-290 | 24V, 80mA, 80 x 80 x 25mm, omniCOOL™ DC軸状ファン | ||
|
CFM-8025C-230-330 | 24V, 110mA, 80 x 80 x 25mm, Dc Fan | ||
|
CFM-8025C-235-364 | 24V, 150mA, 80 x 80 x 25mm, Dc Fan | ||
